EZO-HUM™ Embedded Humidity Probe - Atlas Scientific
EZO-HUM™ Embedded Humidity Probe - Atlas Scientific
From industrial processes to environmental monitoring, this humidity probe can be used in countless applications. With a weather-resistant housing that allows for multiple mounting options, the EZO Embedded Humidity Probe is ready to go, whether you’re monitoring the humidity levels inside a home, workspace or even outside. The EZO Embedded Humidity Probe gives the same readings as our EZO-HUM Circuit. There is no difference in the readings or accuracy, only the design.
This probe comes fully calibrated and ready to use right out of the box.
The EZO-HUM™ comes with:
One embedded Humidity probe, one data cable with 5 pin male header, and one Locknut & O-ring.
Specifications:
| Reads | Relative humidity |
| Dew point | |
| Air temperature | |
| Range | 0 – 100% |
| Calibration | Factory calibrated |
| Response time | 1 reading per second (UART mode) |
| 1 reading per 300 milliseconds (I2C mode) | |
| Accuracy | +/- 2% |
| Connector | 5 lead data cable |
| Cable length | 1 meter |
| Data protocol | UART & I2C |
| Default I2C address | 111 (0x6F) |
| Data format | ASCII |
| Operating voltage | 3.3V − 5V |
| IP rating | IP67 (waterproof up to 1 meter) |
| Life expectancy | 10 years |
Documents
- Arduino Uno Sample Code
- Arduino Mega Sample Code
- Arduino I2C Sample Code
- Raspberry Pi Sample Code (I2C)
