Adapter Click™ is a breakout board which simplifies connection of add-on boards with IDC10 headers to mikroBUS™ socket. There are two ways of establishing connection: using male or female IDC10 connectors. Both are provided with the package. You may solder male IDC10 header on the top side of Adapter Click™ and connect the add-on board directly or via IDC10 flat cable. In some cases, female header socket is a better choice. Solder it either on the top, or the bottom side, depending on which one is more convenient in given circumstances. Each mikroBUS™ line is covered, except AN and RST. There are two jumpers for SPI/I2C selection and one for selection of power supply range.
Specifications
Type | Adapter |
Applications | Adapter Click helps you to easily connect IDC10 add-ons to your seventh generation development boards with mikroBUS sockets |
On-board modules | male or female IDC10 connectors |
Key Features | Connect the add-on board directly or via IDC10 flat cable |
Key Benefits | Simplifies connection of add-on boards with IDC10 headers to mikroBUS socket |
Interface | SPI,PWM,UART,I2C |
Input Voltage | 3.3V or 5V |
Compatibility | mikroBUS |
Click board size | S (28.6 x 25.4 mm) |
