Industrial Liquid Level Sensor MODBUS RS485 Aviation Connector 5m

  • $249.00
  • Save $50
  • (Exc. GST)

  • Available in stock

  • $ We Ship from our stock in AU (Perth) with pickup option, and Prices are Exc. GST
  • $ We Offer Quantity Discounts for Large Orders 10+ qty (Request for Quote)
  • $ We Accept Purchase Orders & Net 30 Payment for Eligible Accounts

    Industrial Liquid Level Sensor MODBUS RS485 Aviation Connector 5m

    The Liquid Level Sensor is designed with industry-grade standards, for monitoring water level, oil level, and other mild-corrosive liquid levels. It incorporates stainless steel and insulated rubber is IP68 rated, is suitable for application in severe environments, and uses the RS485 Modbus-RTU Protocol.


    • Strong anti-interference and long-term stability
    • Anti-corrosion  material,  excellent  anti-corrosion  performance, and durable
    • Anti-blocking design, easy to clean
    • Modbus-RTU  RS485  protocol, can  be  used  with a display  device, PLC, inverter, recorder, and other instruments
    • The  shell  is  made  of  stainless  steel  and  durable,  and  with  waterproof cable, safe to use


    The liquid level sensor measures the height of the liquid and converting it to the Modbus-RTU protocol. It works with a data logger or other devices that support the RS485 Modbus-RTU protocol.

    The liquid level sensor has a built-in high-performance and highly sensitive silicon piezoresistive core. The internal chip converts the sensor's millivolt signal into a standard protocol which can be connected to a computer, control instrument, or PLC.

    It's small-size, lightweight, and easy to install. It has a stainless steel sealing structure that can work in a corrosive environment. The sensor has high anti-vibration and anti-impact performance. It can be widely used in process control, aviation, aerospace, automobile, medical equipment, HVAC, and other applications.



    • Reservoir detection
    • Pool pump station
    • River monitoring
    • Marine monitoring
    • Lake monitoring
    • Sewage treatment
    • Deep well level monitoring
    • Tank level monitoring

    Application Scenarios

    This industrial liquid level sensor can be used in many application scenarios such as pool depth level monitoring, river water level monitoring, marine monitoring, dam and lake water level monitoring, reservoir level monitoring, wastewater level monitoring for sewage treatment, well level monitoring, and liquid level monitoring in tanks, etc.


    Measurement Range 0 ~ 5 meters
    Cable Length 5.3 meters
    Output Signal RS485 Modbus-RTU Protocol
    Accuracy ± 0.25%F.S
    Zero Temperature Drift ± 0.03%F.S/℃
    Sensitivity Temperature Drift ± 0.03%F.S/℃
    Long-term Stability ≤0.2%F.S/year
    Response Time 5ms( (≤90%F.S)
    Measurement Liquid  Slight corrosive liquid (water, edible oil, etc.)
    Power Supply 11-30V DC
    Overload Capacity 200%F.S
    Compensation Temperature -10℃ ~ +70℃
    Medium Temperature  -40℃ ~ +80℃
    Storage Temperature -40℃ ~ +85℃

    304 stainless steel shell,

    316L stainless steel core,

    special rubber-insulated cable.

    IP Rating IP68
    Device Weight 670g
    Certifications  CE, FCC, RoHS
