    RS485-NB RS485/UART to NB-IoT Converter Sensor Node

    The Dragino RS485-NB is a RS485 / UART to NB-IoT Converter for Internet of Things solutions. User can connect the RS485 or UART sensor to the RS485-NB converter, and configure RS485-NB to periodically read sensor data and upload via NB-IoT network to IoT server.

    RS485-NB can interface to the RS485 sensor, 3.3v/5v UART sensor, or interrupt sensor. RS485-NB provides a 3.3v output and a 5v output to power external sensors. Both output voltages are controllable to minimize the total system power consumption.

    RS485-NB supports different uplink methods including MQTT, MQTTs, UDP & TCP for different application requirement, and support uplinks to various IoT Servers.

    RS485-NB supports BLE configure and OTA update which make users easy to use.

    RS485-NB is powered by an 8500mAh Li-SOCI2 battery, it is designed for long-term use up to several years.

    RS485-NB has an optional built-in SIM card and default IoT server connection version. Which makes it work with simple configuration.

    Features:

    • NB-IoT Bands: B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66/B70/B85 @H-FDD
    • Ultra-low power consumption
    • Support multiply RS485 devices by flexible rules
    • Support Modbus protocol
    • Support Interrupt uplink
    • Supports connecting UART sensors with 3.3V or 5V
    • Multiply Sampling and one uplink
    • Support Bluetooth v5.1 remote configure and update firmware
    • Uplink via MQTT, MQTTs, TCP, or UDP
    • Uplink on periodically
    • Downlink to change configure
    • 8500mAh Battery for long-term use
    • Nano SIM card slot for NB-IoT SIM

    Specifications:

    Common DC Characteristics:

    • Supply Voltage: 2.5v ~ 3.6v
    • Operating Temperature: -40 ~ 85°C

    I/O Interface:

    • Battery controllable output (2.6v ~ 3.6v depends on battery)
    • +5v controllable output
    • 1 x RS485 Interface
    • 1 x UART Interface , 3.3v or 5v
    • 1 x Interrupt or Digital IN/OUT pins
    • 1 x I2C Interface
    • 1 x one wire interface

    NB-IoT Spec:

    NB-IoT Module: BC660K-GL

    Support Bands:

    • B1 @H-FDD: 2100MHz
    • B2 @H-FDD: 1900MHz
    • B3 @H-FDD: 1800MHz
    • B4 @H-FDD: 2100MHz
    • B5 @H-FDD: 860MHz
    • B8 @H-FDD: 900MHz
    • B12 @H-FDD: 720MHz
    • B13 @H-FDD: 740MHz
    • B17 @H-FDD: 730MHz
    • B18 @H-FDD: 870MHz
    • B19 @H-FDD: 870MHz
    • B20 @H-FDD: 790MHz
    • B25 @H-FDD: 1900MHz
    • B28 @H-FDD: 750MHz
    • B66 @H-FDD: 2000MHz
    • B70 @H-FDD: 2000MHz
    • B85 @H-FDD: 700MHz

    Battery:

    • Li/SOCI2 un-chargeable battery
    • Capacity: 8500mAh
    • Self Discharge: <1% / Year @ 25°C
    • Max continuously current: 130mA
    • Max boost current: 2A, 1 second

    Power Consumption:

    • STOP Mode: 10uA @ 3.3v
    • Max transmit power: 350mA@3.3v
